Main Specification

Measurement Range	0-6 kΩ
Current Rating	upto 50 A
Accuracy	±0.1% reading
Display	LCD
Temperature Compensation	Automatic correction
Data Storage	Internal memory
Operating Temperature	'-10-50°C
Power Supply	220V AC ± 10% , 50 Hz

Winding Resistance Meter

A Winding Resistance Meter measures the DC resistance of transformer, motor, and generator windings to detect issues such as shorted turns, loose connections, and contact problems, ensuring optimal performance and reliability.

Measures DC resistance of transformers, inductors, reactors, motors and other variety of other loads.
Optional OLTC Test Feature to check the current Vs time characteristics during the tap change.
Comes with Data management software.
Built-in thermal printer.
Communication with RS232 and USB interface.
Internal memory to store up to 200 data test.
Suitable for a wide range of factory, on-site measurement and performance testing applications

Key Features & Benefits

Accurate Resistance Measurement
Automatic Demagnetization
Portable & User-Friendly
