CT & PT Analyzer | ATPL ITA-2000C

A CT (Current Transformer) & PT (Potential Transformer) analyzer is an electrical testing device used to accurately measure and assess the performance, ratio, and phase angle of current and voltage transformers, ensuring proper operation, calibration, and safety in power systems.

Designed for Testing & verification of measurement and protection class of Instrument Transformers
Latest innovation eliminating the need of bulky & expansive test system
Perform various tests such as ratio & phase angle error, error/excitation curve, winding resistance etc.
Test without any changes of wiring as per IEC/ANSI standards enabled through single unit
Carry out testing of Low Voltage and High Voltage CT & PT (CT Ratio up to 35000, PT Ratio up to 35000)
Ability to record up to 1000 tests and facilitates USB, RS232 & Ethernet Port.

Datasheet

Technical Specifications

CT Test Parameters	ITA-2000C
Turns Ratio	up to 35,000
Phase Angle Measurement	0 to 180 degree
Winding Resistance	1 mΩ to 8000Ω
CT Burden Impedance	0.5 Ω to 160 Ω
PT Test Parameters
Turns Ratio	up to 35,000
Phase Angle Measurement	0 to 180 degree
Winding Resistance	2/20/80/800/8000 Ω
PT Burden Impedance	800/8000/80000 Ω
Capacitive VT Test Parameters
Voltage Output	0 to 2050 V AC
Current Output	0-1 Amp
Turns Ratio	up to 8000
Phase Angle Measurement	300 to 8000 Volts
Winding Resistance	1 mΩ to 30 Ω
Inductive VT Test Parameters
Voltage Output	0 to 300 V AC
Current Output	0-1 Amp
Turns Ratio	1 to 245 kV
Phase Angle Measurement	350 to 2450 Volts
Winding Resistance	1 mΩ to 30 Ω
General
Current Measurement	0 to 10 A
Voltage Measurement	0 to 200 V
Temperature Measurement	50-100 deg. C
