Oil Breakdown Voltage Kit | ATPL ATODT - 100 PR

Oil Breakdown Voltage (BDV) Test Kit is an essential device used to measure the dielectric strength of insulating oils in transformers, capacitors, and other high-voltage electrical equipment. This testing ensures the oil’s insulation quality, helping to prevent electrical failures, improve equipment performance, and extend operational lifespan. Ideal for routine maintenance and quality control, a BDV test kit plays a critical role in maintaining the safety and reliability of power systems.

Latest technology for superior performance and operator safety.
Available in 3 different types- Motorized, Semi-automatic and Fully Automatic.
Testing facility according to various pre-defined international testing standards.
Designed according to national standard IS 6792 for testing of Oil Dielectric Strength
Designed for Automatic as well as Manual mode of operation.
Includes PC software for report generation

Datasheet

Technical Specifications

Parameter Names	ATODT-100 PR
Test Voltage	0 - 100 kV AC
Rate of Voltage Rise	0.5 k V/s, 2 kV/s, 3 kV/s & 5 kV/s
Power Supply Input	230 ± 10 % Volts, 50 Hz AC
Stir Time	0 - 999 Sec
Temperature Accuracy	± 1°C
Measurement Error	± 1 %
Interfaces	RS232 (for PC connection)
Printer	Built-in Micro Printer
Display	LCD
Weight	38 Kg (Approx.)
Dimensions	550mm x 500mm x 580mm (Approx.)
Operating Temperature	0°C to 50°C
