Description

The HVDC Power Filter Characteristic Tester evaluates harmonic performance, filter response, and impedance of HVDC power systems, ensuring efficient operation, reliable measurements, and fast, portable, and user-friendly field testing.
• Automatically generate harmonic signal output, measuring and displaying A-F and P-F characteristics.
• Determine impedance frequency, current, phase frequency, resistance, inductance, and capacitance.
• Primarily utilized for assessing power filters in UHV converter stations, as well as HV filters in electrified railway systems and passive power filter applications.
• Capable of measuring capacitance without the need to disconnect capacitor banks.
